AMEC 1-3V235JA Heavy Duty QD Bushed Sheave, 3V Belt Belt, 1 Groove, 2.35" OD
AMEC 1-3V235JA Heavy Duty QD Bushed Sheave, 3V Belt Belt, 1 Groove, 2.35" OD
Precio habitual
$18.24 USD
Precio habitual
Precio de oferta
$18.24 USD
Precio unitario
/
por
Los gastos de envío se calculan en la pantalla de pago.
No se pudo cargar la disponibilidad de retiro
Part Number |
1-3V235JA
|
Belt Section Size |
3V Belt |
Bore Type |
QD Bushed |
Bushing Bore Range |
1/2" - 1-1/4"; 15 mm - 28 mm |
Bushing Type |
QD |
Bushing Size |
JA |
Face Width |
0.689" |
Length Through Bore |
1" |
Number of Grooves |
1 |
Material |
Cast Iron |
Finish/Coating |
Gray Paint |
Pitch Diameter |
2.3" |
Sheave Construction |
Solid |
Side Face Offset |
0.516" |
Outer Diameter |
2.35" |
Overall Height |
2.35" |
Overall Length |
2.35" |
Overall Width |
0.687" |
weight |
0.66 |
