Donaldson Filtration M120418 MUFFLER, OVAL STYLE 6

Attributes
Flow Direction Inlet-Outlet
Inlet Diameter 5.03 inch (127.64 mm)
Outlet Diameter 5.03 inch (127.64 mm)
Body Diameter Minimum 10.00 inch (254 mm)
Body Diameter Maximum 15.00 inch (381 mm)
Body Length 27.50 inch (698.5 mm)
Overall Length 28.26 inch (717.7 mm)
Rated Flow LR 1356 cfm (38.4 m³/min)
Rated Flow MR 1918 cfm (54.3 m³/min)
Rated Flow HR 2348 cfm (66.5 m³/min)
Back Pressure Low-Range 0.98 inch Hg (25 mm Hg)
Back Pressure Mid-Range 2.01 inch Hg (51 mm Hg)
Back Pressure High-Range 2.99 inch Hg (76 mm Hg)
Attenuation LR 15 dBA
Attenuation HR 20 dBA
Inlet Clock Position 6:00
Outlet Clock Position 12:00
Style Style 6
Price Type E
Packaged Dimensions
Packaged Length 31.25 inch (79.375 cm)
Packaged Width 16.50 inch (41.910 cm)
Packaged Height 16.25 inch (41.275 cm)
Packaged Weight 31.55 lb (14.324 kg)
Packaged Volume 4.85 ft3 (0.136 m3)
Pieces Per Pallet 6
Other Information
Country of Origin United States
NMFC Code 125850-01
HTS Code 8708925000
UPC Code 742330006009
