Donaldson Filtration DBL7405 Lube Filter, Spin-On Full Flow Donaldson Blue

Why Choose Donaldson Blue® Filters?
Donaldson Blue® lube filters are designed specifically for
extended maintenance programs.
• Proven Synteq™ – media delivers greater efficiency and
higher contaminant holding capacity.
• Removes more than 90% of contaminants 10 microns or
larger (cellulose filters typically remove 50% or less).
• Twice the contaminant holding capacity of standard
cellulose filters – for longer filter life.
• Direct replacements to standard filters – no system
modifications.
Attributes
Outer Diameter 4.65 inch (118 mm)
Thread Size 1 1/2-16 UN
Length 11.73 inch (298 mm)
Gasket OD 4.33 inch (110 mm)
Gasket ID 3.86 inch (98 mm)
Efficiency 99% 15 micron
Efficiency Test Std ISO 4548-12
Media Type Synteq
Collapse Burst 149 psi (10.3 bar)
Type Full-Flow
Style Spin-On
Brand Donaldson BLUE®
Price Type F
Packaged Dimensions
Packaged Length 4.6 IN
Packaged Width 4.5 IN
Packaged Height 11.7IN
Packaged Weight 3.495 LB
Packaged Volume 0.1402 FT3
Pieces Per Pallet 270
Other Information
Country of Origin United States
NMFC Code 069100-05
HTS Code 8421230000
UPC Code 742330018262
