Donaldson Filtration P584250 HYDRAULIC FILTER, SPIN-ON

 Why Choose Donaldson Spin-On Filters
• High-performance Hydraulic Spin-On filters utilize
Donaldson media technology which undergoes stringent
design and testing which sets the standard in filtration
performance.
• Donaldson Media Formulations provide superior hydraulic
system protection.
• Donaldson offers the largest selection of replacement
hydraulic Spin-On filters for greater contamination control
• A variety of filters which meet and/or exceed OEM
specifications
Attributes
Seal Material Fluorocarbon
Outer Diameter 2.18 inch (55.3 mm)
Inner Diameter 1.02 inch (26 mm)
Length 2.83 inch (71.9 mm)
Gasket ID 0.96 inch (24.3 mm)
Efficiency Beta 1000 5 micron
Collapse Burst 450 psi (31 bar)
Media Brand DT High-Performance
Media Type Synthetic
Price Type FH
Packaged Dimensions
Packaged Length 0.39 FT
Packaged Width 0.39 FT
Packaged Height 0.50 FT
Packaged Weight 0.41 lb (0.186 kg)
Packaged Volume 0.04 ft3 (0.001 m3)
Other Information
Country of Origin United States
NMFC Code 069100-05
HTS Code 8421290040
UPC Code 742330257661
